This is the FLIR E85 - a powerful, handheld thermal imaging system that's suitable for everything from electrical studies to detecting building insulation problems. The E85 is the upgraded version of FLIR's E75 camera. Both models are basically identical - however the E85 has higher thermal resolution of 384 x 288 pixels (the E75 has 320 x 240 pixel resolution) and packs more temperature data into every image taken on the camera. This camera also has more spotmeter and area box images, allowing you to add 3 of either to images in live viewing.
Using the FLIR E85 is simple - it's ergonomically designed with pistol-shaped grips and a trigger for quick, easy image capturing.A large-size, fast-response touchscreen gives you quick and easy access to all functions, allowing you to swap between modes with just a few taps. Multiple colour palettes are included, as well as FLIR's unique MSX technology which actively blends together thermal and digital images to increase the level of detail in every image captured on the E85.
There's much more to this camera too; it includes 1 to 4x continuous digital zoom, a built-in digital camera, removeable and replaceable lenses, a picture-in-picture mode and a wide temperature measurement range from -20 to 1200°C.
FLIR E85 Thermal Camera Key Features
Upgraded resolution compared to the E75 - 384 x 288 pixels
Capture both infrared and digital reference images using built-in thermal and digital cameras
Picture-in-picture mode - add a window of thermal to a digital image to isolate specific problems
Automatic hot and cold detection - automatically adds maximum/minimum markers within an area
Isotherm colour alarm - set above, below, interval, condensation and insulation alarms to instantly detect problems within buildings
Adjustable emissivity to cater for use on different types of surface
Selectable colour palettes - choose between iron, grey, rainbow, arctic, lava and rainbow high contrast
High quality touchscreen with auto orientation
Thumbnail image gallery to easily swap between images
Wide temperature measurement range from 0 to 650°C
Moisture and insulation alarms
Removable SD card memory (8GB included as standard)
Add voice text annotations to your images (up to 60 seconds) using built-in microphone and speaker
Add text annotations using predefined entries or set your own using the touchscreen
Sketch on images directly using the touchscreen
METERLiNK mode - allows the camera to connect wirelessly to other compatible FLIR/Extech testing tools for more complete readings
Integrated compass adds GPS data and image orientation to captured images
Radiometric and non-radiometric video recording and streaming
5MP digital camera with built-in LED light
Laser pointer for added precision when lining up images
USB, Bluetooth and WiFi interfaces
Powered by rechargeable batteries - up to 2.5 hours operating time with field-swappable batteries
Tripod mount - UNC 1/4" - 20
What's Included?
FLIR E85 Thermal Camera
2 x Rechargeable Batteries
Lenses (As Selected Above)
Hand Strap
Hard Transport Case
Lanyards for Battery Charger and Camera
Lens Caps
Lens Cleaning Cloth
Power Supply for Battery Charger
Power Supply, 15W/3A
Printed Documentation
SD Card (8GB)
Torx Screwdriver
USB 2.0A to USB Type-C cable, 1m
USB Type-C to HDMI Cable
USB Type-C to USB type-C cable, 1m
Wrist Strap
